車用懸吊系統&手工具
.jpg)
橡膠軸套
橡膠軸套
| Specificiation | Ø mm | Dimensions(mm) | ||||||
| YS-AIR | OE Reference | A | B±0.3 | C | D± 0.3 | h1 | h2 | H |
| YS-01S | FUSO | 58 | 63.5 | 81.5 | 87 | 28 | 72 | 190±2 |
| YS-02S | FUSO | 58 | 63.5 | 81.5 | 87 | 28 | 52 | 165±2 |
| YS-03S | FUSO | 58 | 63.5 | 81.5 | 87 | 20 | 45 | 145±2 |
| YS-04S | FUSO,HINO | 79.2 | 84.5 | 113 | 118.5 | 26 | 44 | 136±2 |
| YS-05S | Seat | 69.5 | 75 | 69.5 | 75 | - | - | 186±2 |
| YS-06S | Man,Scania | 75 | 80.5 | 75 | 80.5 | - | - | 316±2 |
| YS-07S | Seat | 48 | 53.5 | 78 | 83.5 | 22 | 78 | 186±2 |
| YS-08S | 82 | 85.8 | 82 | 85.8 | - | - | 200±2 | |
| YS-09S | 90 | 93.8 | 90 | 93.8 | - | - | 270±2 | |
| YS-10S | 86 | 89.8 | 86 | 89.8 | - | - | 135±2 | |
| YS-11S | 82 | 85.8 | 82 | 85.8 | - | - | 268±2 | |
| YS-12S | Scania | 78 | 80.5 | 75 | 80.5 | - | - | 360±2 |
| YS-13S | Volvo | 80 | 85.5 | 100 | 105.5 | 28 | 72 | 445±2 |
| YS-14S | 86 | 89.8 | 86 | 89.8 | - | - | 230±2 | |
| YS-15S | Benz W211,Front COVER | 120 | 125.8 | 120 | 125.8 | - | - | 75±2 |
| YS-16S | 93 | 98.6 | 122 | 127.6 | 40 | 72 | 305±2 | |
| YS-17S | 92 | 95.8 | 92 | 95.8 | - | - | 128±2 | |
| YS-18S | Audi All Road | 87 | 92.6 | 108 | 113.6 | 40 | 72 | 312±2 |
| YS-19S | TAHOE | 54 | 59.6 | 67 | 72.6 | 120 | 120 | 320±2 |
| YS-20S | Benz W211,Rwar | 96 | 101.6 | 96 | 101.6 | - | - | 210±2 |
| YS-21S | GL/ML W164 Front | 96 | 101.6 | 126 | 131.6 | 40 | 72 | 376±2 |
| YS-22S | 82 | 85.8 | 82 | 85.8 | - | - | 285±2 | |
| YS-23S | W251 | 98 | 103.6 | 122 | 127.6 | 40 | 72 | 305±2 |
| YS-24S | BMW X5 | 91 | 96.4 | 133 | 138 | - | - | 295±2 |
| YS-25S | Benz 220,front | 86 | 90 | 122 | 125.6 | 28 | 28 | 135±2 |
| YS-26S | Benz 220 Rear | 82 | 86 | 97 | 100.6 | 28 | 28 | 268±2 |
| YS-27S | W211,Fornt | 86 | 89.6 | 116 | 109.6 | 28 | 28 | 230±2 |
| YS-28S | W211,Rear | 89 | 93.1 | 124.5 | 128.1 | 35 | 35 | 156±2 |
| YS-29S | W211,Front | 89 | 93.1 | 124.5 | 128.1 | 28 | 28 | 132±2 |
| YS-30S | Audi A8 | 80 | 83.6 | 119 | 122.5 | 28 | 28 | 230±2 |
| YS-31S | 82 | 86 | 97 | 100.6 | 28 | 28 | 278±2 | |
| YS-32S | BMW L | 82 | 86 | 97 | 100.6 | 30 | 30 | 283±2 |
| YS-33S | BMW F02 F01 | 89 | 93.1 | 124.5 | 128.1 | 40 | 40 | 170±2 |
| YS-34S | BMW G12 Rear | 80 | 83.6 | 119 | 122.5 | 25 | 25 | 210±2 |
| YS-35S | #251 | 98 | 103.6 | 122 | 127.6 | 90 | 90 | 350±2 |
| YS-36S | BENTLEY VW | 80 | 83.6 | 119 | 122.5 | 40 | 40 | 180±2 |
| YS-37S | 75 | 80 | 84 | 89 | 15 | 15 | 230±2 | |
| YS-38S | 62.4 | 67.4 | 67 | 72 | 15 | 15 | 192±2 | |
| YS-39S | W222 Benz(S400) F | 103 | 106.4 | 137.5 | 140.9 | 15 | 15 | 156±2 |
| YS-40S | W222 Benz(S400) R | 103 | 106.4 | 137.5 | 140.9 | 26 | 26 | 178±2 |
| YS-41S | W212 | 76 | 78.4 | 125 | 128.4 | 26 | 26 | 235±2 |
| YS-42S | MACAN PANAMER | 82 | 85.4 | 115 | 121 | 54 | 90 | 210±2 |
| YS-43S | ML164 | 98 | 103.6 | 122 | 127.6 | 27 | 60 | 280±2 |
| YS-44S | NEW A8,NEW BENTLEY | 80 | 83.6 | 119 | 122.5 | 25 | 25 | 190±2 |
| YS-45S | BMW G12 Front | 82 | 83.6 | 127.5 | 131.9 | 25 | 25 | 183±2 |
